Relay circuits are a cornerstone in modern electrical and electronic systems, enabling the control of high-voltage devices with low-voltage signals. These circuits are widely used in applications ranging from automotive systems to industrial control panels and even home automation. Understanding the basics of relay circuit design is essential for engineers, hobbyists, and anyone interested in circuit building.
What is a Relay? At its core, a relay is an electromechanical device that uses an electromagnet to control the switching of electrical contacts. When an electric current passes through the coil of the relay, it creates a magnetic field that attracts a movable armature, which in turn changes the state of the relay’s contacts. The contacts can either open or close, depending on whether the relay is of the normally open (NO) or normally closed (NC) type. Relays are typically used to switch higher-power circuits using low-power signals. This makes them an ideal component in scenarios where a microcontroller or other low-power system needs to control high-current loads like motors, lights, or heating elements.
